PEERLESS PUREFIRE PF-850 - Page 83

81
REPAIR PARTS
Table 13.3: Jacket Assembly
Description
Quantity
Required
Stock
Code
1 Heat Exchanger Support Panel – Front 1 PF2016
2 Heat Exchanger Support Panel – Rear 1 PF2017
3
Heat Exchanger Support Rails – PF-850 4 PF2018
Heat Exchanger Support Rails – PF-1000 4 PF-2018-1
4 Blower Cabinet Frame Assembly 1 PF2027
5 Blower Cabinet Support Rails 2 PF2026
6
Electrical Terminal Enclosure – PF-850 1 PF2029
Electrical Terminal Enclosure – PF-1000 1 PF2029-1
7
Terminal Enclosure Cover – PF-850 1 PF2030
Terminal Enclosure Cover – PF-1000 1 PF2030-1
8 Thermal Fuse Cover 2 PF2031
9 Blower Cabinet Floor Pan 1 PF2033
10
Condensate System Tray – PF-850 1 PF5027
Condensate System Tray – PF-1000 1 PF5027-1
11 Air Inlet Plenum Assembly 1 PF5044
12 Blower Cabinet Top Panel 1 PF6067
13
Side Heat Exchanger Access Panel – PF-850 2 PF6064
Side Heat Exchanger Access Panel – PF-1000 2 PF6064-1
14
Top Heat Exchanger Access Panel – PF-850 1 PF6066
Top Heat Exchanger Access Panel – PF-1000 1 PF6066-1
15 Blower Cabinet Right Side Panel 1 PF-6067
16 Blower Cabinet Left side Panel 1 PF-6067-1
17 Air Inlet Screen 1 54447
18 Ball Studs 30 5433
19 Front Cover Panel 1 54292
20 Control Lens 1 54127
21 Leveling Legs 6 5659
22 Tubing Connector 1 50770
23 1/4" Rubber Grommet 1 6158
