REPAIR PARTS
Table 13.4: Control System
Description
Quantity
Required
Stock
Code
1 Integrated Primary Controls 2 54440
2 User Interface Pixel Display 1 54441
3 Installer Interface LED Display 2 54445
4 Interface Module 1 54442
5 Pump Relay Module 1 54437
6 Terminal Block – 10 Pole 2 5450
7 Terminal Block – 6 Pole 2 5547
8 Ignition Cable 2 54115
9 Harness J5M Managing Control Sensors (not shown) 1 54448
10 Harness J5D Dependent Control Sensor (not shown) 1 54449
11 Harness J15M Managing Flapper/Limits (not shown) 1 54450
12 Harness J15D Dependent Flapper/Limits (not shown) 1 54451
13 Harness J2M Managing Control/Blower Power (not shown) 1 54452
14 Harness J2D Dependent Control/Blower Power (not shown) 1 54453
15 Harness J13M Managing Gas Valve/Flame Sensor/High Limit (not shown) 1 54454
16 Harness J13D Dependent Gas Valve/Flame Sensor/High Limit (not shown) 1 54455
17 Harness J7M Managing Gen Circulator (not shown) 1 54456
18 Harness J6M Managing CH/DHW Circulator (not shown) 1 54457
19 Harness Line Voltage Terminal Strip/Power Switch/Relay Module (not shown) 1 54458
20 Harness J9 Blower Control (not shown) 2 54459
21 Harness Managing Thermal Fuse w/ Conduit (not shown) 1 54460
22 Harness Dependent Thermal Fuse w/ Conduit (not shown) 1 54461
23 Harness Ground 2 PF7009
24 Rocker Switch 2 6049
