ECP300 EXPERT

Pag. 14

USE AND MAINTENANCE MANUAL

Rev. 0

Fig. 4: Close the transparent protection cover.

Fig. 5: Open the front of the box, lift it and

slide the two hinges out as far as they

will go.

Fig. 6: Bend the hinges and rotate the front

panel by 180° downward to get access

inside the panel; then disconnect the

connector to electronic card.

CHAP. 3 - Installation
