ECP300 EXPERT

Pag. 16

USE AND MAINTENANCE MANUAL

Rev. 0

Fig.10: Using holes made on previous point fix

the bottom with 4 screws of a length

suitable for the thickness of the wall to

which the panel will be attached. Fit a

o-ring (supplied) between each screw

and the box backing.

Fig.11: Now make the electrical wirings as

indicated in the next chapter

CHAP. 3 - Installation
