SGM700 Digitizer
Configuration Menu -Eth-
6.6 - - - Eth Ethernet settings (SGM720 only)
In this menu, the communication settings can be set for the ethernet port.
Options are:
Press key 2 <2 sec to enter the ethernet settings.
The following screen is vissable:
33
Adr 1 First three numbers of the IP address
Adr 2 Second three numbers of the IP address
Adr 3 Third three numbers of the IP address
Adr 4 Fourth three numbers of the IP address
Sub 1 First three numbers of the Subnet address
Sub 2 Second three numbers of the Subnet address
Sub 3 Third three numbers of the Subnet address
Sub 4 Fourth three numbers of the Subnet address
gAt 1 First three numbers of the Gateway address
gAt 2 Second three numbers of the Gateway address
gAt 3 Third three numbers of the Gateway address
gAt 4 Fourth three numbers of the Gateway address
