10. Profibus Protocol Description
Module = "weight" 0x28, 0x1E
; gross 32 bits inputs
; net 32 bits inputs
; tare 32 bits inputs
; status 16 bits inputs
; cmd 8 bits inputs
; level1 32 bits outputs
; level2 32 bits outputs
; cmd 8 bits outputs
;
; cmd bit definitation:
; 1 = zero reset command
; 2 = zero set command
; 3 = tare off
; 4 = tare on
; 5 = free
; 6 = free
; 7 = free
; 8 = free
;
; status bit definitation:
; 1 = hardware overload detected
; 2 = overload detected
; 3 = stable signal
; 4 = in stable range
; 5 = zero corrected
; 6 = center of zero
; 7 = in zero range
; 8 = zero tracking posible
; 9 = tare active
; 10 = preset tare active
; 11 = new sample available
; 12 = calibration invalid
; 13 = calibration enabled
; 14 = user certified operation
; 15 = level 1 active
; 16 = level 2 active
EndModule
