PENKO SGM700 - 3 Loadcell Power Conection; SGM700 Basic Digitizer

SGM700 Digitizer
3. Load cell / power connection
3.1 SGM700 basic digitizer
8
Analoge output
Inputs Input 1=5khz 18-28Vdc Outputs 25V/0.5A AC/DC
Local bus
To PC Config software
DC POWER SUPPLY 18-32Vdc 6-Wire load cell connection Vexc=5Vdc
