Chapter 4. Driver Software Functions
This chapter will guide you to the special software functions that configure and adjust the PenMount
control boards and touchscreen hardware. Please note that not all of the functions are available for
every driver. See the following table for drivers’ software functions and their availability for specific
interface and systems:
Software Function
DOS
Windows
2000/XP
Windows
VISTA/7/8
Windows
CE
Linux
Standard Calibration
●
●
●
●
●
Advanced Calibration
●
●
●
●
Multiple Monitors
●
●
Multi Device
●
●
Rotation
●
●
Operation Mode
●
●
Drawing mode
●
●
●
●
Beep Sound
●
●
●
●
Beep sound adjustable
●
●
Wake up function
●
●
Showing linearity
●
●
Right button
●
●
●
●
Hide cursor
●
Double click area and
speed adjustable
●
●
About
●
●
Edge Compensation
●
●
Refresh
●
●
Remark:
With PenMount Windows Universal V2.2.0.283 and later versions, since the touchscreen is automatically
installed as a digitizer device in Windows Vista/7/8, the functions which are built within Windows Vista/ 7/
8 such as rotation, multi-monitors, flicks, and context menu function (which launches a context menu by
user’s long-pressing on touchscreen rather than clicking the right-mouse button or pressing the
application key on the keyboard) will be supported.
The following content in this chapter deals mainly with PenMount Windows Universal Driver (for
2000/XP/2003/VISTA/7/8). The PenMount Control Panel, which can be launched either in the start
menu, or by double click on the desktop icon, is the major configuration utility.
4.1. Calibration
The most important feature that PenMount Control Panel provides is calibration. Please
click on the “PenMount 6000 USB” or “PenMount 6000 RS232” icon to open the device
specific configuration window.
