4. Operating Software OS6.0
The device is parameterized via the serial interface using a PC and the OS6.0
operating software.
The free operating software OS6.0 can be found at Pepperl-Fuchs.com
This section shows the overview of the individual menus and their parameters.
Menu
Parameter
GENERAL MENU
MODE
ENCODER PROPERTIES
ENCODER DIRECTION
FACTOR
DIVIDER
ADDITIVE VALUE
LINEARIZATION MODE
BACKUP MEMORY
FACTORY SETTINGS
FREQUENCY MODE
FREQUENCY MODE
FREQUENCY BASE
SAMPLING TIME 1 (S)
WAIT TIME 1 (S)
STANDSTILL TIME 1 (S)
AVERAGE FILTER 1
SAMPLING TIME 2 (S)
WAIT TIME 2 (S)
AVERAGE FILTER 2
COUNTER MODE
COUNT MODE
FACTOR A
SET VALUE A
FACTOR B
SET VALUE B
ROUND LOOP VALUE
SSI MODE
SSI MODE
ENCODER RESOLUTION
DATA FORMAT
BAUD RATE
SSI ZERO
HIGH BIT
