Pepperl+Fuchs K23-SSI/USB/25B-C User Manual

K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
24
Value
Designation
Function
2
4 QUADRANT
Linearization in all four quadrants
BACKUP MEMORY (retentive memory)
Note: Only relevant for MODE: "COUNTER"
Value
Designation
Function
0
NO
No retentive memory
1
YES
Retentive memory active. Stores the actual
value of the counter readings in the event of a
power failure and "counter" mode is switched on.
FACTORY SETTINGS
Value
Designation
Function
0
NO
The factory settings are not loaded
1
YES
The factory settings are loaded
4.2 Frequency Mode
In this menu, the operation is defined as a frequency converter (incremental
signals). Depending on the operating mode set, only channel A or both channels
(channel A and channel B) are active.
FREQUENCY MODE
This parameter determines which operating mode of the frequency measurement
is desired.
Value
Designation
Function
0
A ONLY
Single-channel frequency measurement (only for
channel A).
1
RATIO
Frequency ratio of both channels (channel B /
channel A).
Note: Interpretation of the result with four
decimal places in the format +/- x.xxxx
2
PERCENT
Percentage deviation from channel B to channel
A.
Note: Interpretation of the result with two decimal
places in the format +/- xxx.xx %
3
A + B
Frequency addition of both channels (channel A
+ channel B)
4
A - B
Frequency subtraction of both channels
(channel A - channel B)
