K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
35
ERROR POLARITY
Defines the polarity of the error bit in the event of a fault
Value
Function
0
Bit is low in the event of a fault
1
Bit is high in the event of a fault
Note
SSI values
To process SSI values, see
Appendix
4.5 Start/Stop Mode
In this menu, the operation is defined as a start/stop interface converter.
INIT MODE
Managing or managed operation
Depending on the selected INIT MODE, different terminals must be used for the
init pulse.
Managing operation: Terminal X2—pins 1 and 2
Managed operation: Terminal X2—pins 5 and 6
Value
Designation
Function
0
PRIMARY
Managing operation: Init pulse is generated by the
device
1
SECONDARY
Managed operation: Init pulse is generated
externally
SAMPLING TIME (ms)
Duration between two init pulses in milliseconds. Corresponds to the time after
which a new measurement is started and directly affects the reaction time of the
device.
Value
Function
00.200
Minimum measuring time
04.000
Default value
16.000
Maximum measuring time
