K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
36
INIT PULSE TIME (µs)
This parameter defines the pulse duration of the init pulse in
microseconds.
Value
Function
1
Smallest value
2
Default value
9
Largest value
VELOCITY (m/s)
Waveguide velocity of the encoder used in m/s.
Value
Function
0001.00
Smallest value
2800.00
Default value
9999.99
Largest value
OPERATIONAL MODE
This parameter determines which type of measurement the device is to perform.
Value
Designation
Function
0
POSITION
Distance measurement
1
ANGLE
Angle measurement
2
SPEED
Velocity measurement
Note
For more information on the different "OPERATIONAL MODES" and interpretation of
the respective measurement results, see Chapter 6.7)
OFFSET
In the event of a "Reset/Set Value" command via the control input or the PC user
interface, the current position of the rotary encoder is transferred
in a non-volatile manner to the "OFFSET" parameter. (= zero point shift)
Value
Function
-99999999
Smallest value
0
Default value
99999999
Largest value
