Pepperl+Fuchs K23-SSI/USB/25B-C User Manual

K23-SSI/USB/25B-C | APPENDIX
54
#
Menu
Name
Code
Min.
Max.
Default
127
LINEARIZATION
MENU
P24(Y)
G9
-99999999
99999999
0
5.3 Serial Codes of the Commands
Serial code
Command
54
RESET/SET
55
FREEZE DISPLAY
56
SSI ZERO POSITION
57
RESET/SET COUNTER A
58
RESET/SET COUNTER B
59
LOCK COUNTER A
60
LOCK COUNTER B
61
RESET MIN/MAX
62
FACTORY SETTINGS
63
-
64
-
65
CLEAR LOOP TIME
66
SERIAL PRINT
67
ACTIVATE DATA
68
STORE DATA
69
TESTPROGRAM
5.4 Linearization
This function can be used to convert a linear input signal into a non-linear
representation (or vice versa). Up to 24 linearization points are available, which
can be distributed over the entire conversion range at various distances.
Linear interpolation takes place automatically between two predefined
coordinates.
It is recommended that as many points as possible be positioned in places with
strong curvature. In places with weak curvature, only a few points are needed.
To specify a linearization curve, the LINEARIZATION MODE parameter must be
set to
1 QUADRANT or 4 QUADRANT (see diagram below).
Parameters P1(X) to P24(X) can be used to specify up to 24 X coordinates.
These correspond to display values without linearization.
