K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
32
ROUND LOOP VALUE
Defines the number of encoder steps if a concentricity function is desired. (Only
for COUNT MODE: A SINGLE and A/B x 90)
Value
Function
0
No concentricity
…
99999999
Number of steps for the concentricity function
4.4 SSI Mode
In this menu, the operation is defined as an absolute value converter (SSI
signals).
SSI MODE
SSI setting of the operating mode: Managing or managed
Depending on the SSI MODE, different terminals must be used for the SSI CLK:
Managing operation: Terminal X2—pins 1 and 2
Managed operation: Terminal X2—pins 5 and 6)
Value
Designation
Function
0
PRIMARY
Managing operation: Clock pulse for SSI rotary
encoder is generated by the device.
1
SECONDARY
Managed operation: Clock pulse for SSI rotary
encoder comes from external control.
ENCODER RESOLUTION
Resolution of the SSI rotary encoder (total number of all bits)
Value
Function
10
Smallest value
25
Default value
32
Largest value
DATA FORMAT
Setting of the SSI code (binary or gray)
Value
Designation
Function
0
GRAY CODE
Gray SSI code
1
BINARY CODE
Binary SSI code
