K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
22
Menu
Parameter
P1(Y)
P2(X)
P2(Y)
…
P23(X)
P23(Y)
P24(X)
P24(Y)
4.1 General Menu
MODE (operating mode)
This parameter defines which measurement function (operating mode/mode) the
device should fulfill.
Value
Designation
Function
0
NOT DEFINED
Operating mode: Not defined, modulation and
measurement results are zero
1
FREQUENCY
Operating mode: Frequency converter,
incremental signals
2
COUNTER
Operating mode: Counter, incremental signals
3
SSI
Operating mode: Absolute value converter, SSI
signals
4
START/STOP
Operating mode: Start/Stop interface converter
ENCODER PROPERTIES
This parameter defines the characteristics of the incremental input.
(Note: Only relevant for MODE: "FREQUENCY" and MODE: "COUNTER")
Value
Designation
Function
0
RS422
RS422 standard
1
HTL
DIFFERENTIAL
HTL differential
2
HTL PNP
PNP (switching to +)
3
HTL NPN
NPN (switching to -)
4
TTL PNP
TTL PNP (switching to +)
