K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
23
ENCODER DIRECTION
This parameter reverses the direction of counting and/or travel.
Value
Designation
Function
0
FORWARD
Forward
1
REVERSE
Backward
FACTOR (multiplication factor)
This parameter defines the factor by which the measurement result is
multiplied.
Value
Function
-99999999
Smallest value
1
Default value
99999999
Largest value
DIVIDER (division factor)
This parameter defines the divisor by which the measurement result is divided.
Value
Function
-99999999
Smallest value
1
Default value
99999999
Largest value
ADDITIVE VALUE (additive constant)
This parameter defines an additive constant, which is added to the
measurement result.
Value
Function
-99999999
Smallest value
0
Default value
99999999
Largest value
LINEARIZATION MODE
This parameter defines the linearization function. Note the information in
the appendix!
Value
Designation
Function
0
OFF
No linearization
1
1 QUADRANT
Linearization in the first quadrant
