Pepperl+Fuchs K23-SSI/USB/25B-C User Manual

K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
37
CIRCUMFERENCE (mm)
Sets the reference quantity in mm for an angle measurement.
The distance traveled, e.g., the extent to which to generate the subsequent
ROUND LOOP VALUE, must be set here.
Value
Function
00000.001
Smallest value
01000.000
Default value
99999.999
Largest value
Note
Only for OPERATIONAL MODE: "ANGLE"
ROUND LOOP VALUE
Sets the desired data to be generated when the previous reference quantity
CIRCUMFERENCE is reached.
Note
Only for OPERATIONAL MODE: "ANGLE"
Value
Function
1
Smallest value
360
Default value
99999999
Largest value
AVERAGE FILTER—POSITION
(filter for average determination)
Switchable average determination for preventing position fluctuations.
Value
Function
0
No average determination
1
Flowing average determination with two cycles
2
Flowing average determination with four cycles
3
Flowing average determination with eight cycles
4
Flowing average determination with 16 cycles
