The individual error codes are explained in more detail below:
Error code
(Error_Status)
Error name
Error description
0x00000001
Maximum Value
SPECIAL PIN FUNCTION
“Data-Bit / Data-Bit”:
Measured value is greater than +
16777215 (2^24-1)
SPECIAL PIN FUNCTION
“Error” or “Data – Stable”:
Measured value is greater than +
8388607 (2^23-1)
SPECIAL PIN FUNCTION
“Error” and “Data – Stable”:
(or negated accordingly)
Measured value is greater than +
4194303 (2^22-1)
0x00000002
Minimum Value
SPECIAL PIN FUNCTION:
“Data-Bit / Data-Bit”:
Measured value is less than +
16777216 (2^24)
Special PIN FUNCTION
“Error” or “Data – Stable”:
Measured value is less than -
8388608 (2^23)
SPECIAL PIN FUNCTION
“Error” and “Data – Stable”:
(or negated accordingly)
Measured value is less than -
4194304 (2^22)
0x00000004
SSI Encoder Error
SSI Error bit set
(SSI mode only)
0x00000010
Frequency (Input A)
out of range
The maximum or minimum
permissible input frequency at input
A was exceeded or not reached with
the exponential filter setting used.
(Frequency mode only)
0x00000020
Frequency (Input B)
out of range
The maximum or minimum
permissible input frequency at input
B was exceeded or not reached with
the exponential filter setting used.
(Frequency mode only)
0x00000040
Start/Stop Encoder
Error
No "start" and no "stop" pulse
detected between two "init" pulses.
(only for mode: Start/Stop)
