HART Loop Converter KFD2-HLC-(Ex)1.D(.**)
Editing device data: Parameterization mode
18
8.1.3 Navigation method
The following diagram illustrates the navigation method in parameterization mode using the S, T, OK
and ESC keys:
Iout1
OK →
Assignment
←
ESC
TS
Characteristic
OK →
4 - 20 NE43
←
ESC ←
ESC
TS
Start value
←
ESC
TS
End value
←
ESC
TS
Error current
←
ESC
