HART Loop Converter KFD2-HLC-(Ex)1.D(.**)
Editing device data: Relay
28
8.5.1 Trip value
The following illustrations show the menu levels that follow the Trip value menu item (see section 8.5).
Items from the lowest menu level are outlined in bold.
If the Trip value function is enabled (On), press the OK key in the Trip value menu item to access the
Assignment menu item. If you enable the Trip value function again (see section 8.5), pressing the OK
key a second time gives direct access to the Assignment menu item.
Output —— Iout1
Iout2
Iout3
Rel1 —— Trip value (8.5.1)
Fault indication (8.5.7)
Rel2
Rel3
Rel4
To Next Page
