Date of issue 11/30/07 805639
HART Loop Converter KFD2-HLC-(Ex)1.D(.**)
Editing device data: Current outputs
24
8.4 Current outputs
The following illustrations show the current output menus. Items from the lowest menu level are
outlined in bold.
Pressing the OK key in the Iout1, Iout2 and Iout3 menu items gives you access to a menu for entering
separate parameters for the selected current output. The three menus are identical and are therefore
described only once. For the relay outputs on the KFD2-HLC-(Ex)1.D.2W or KFD2-HLC-(Ex)1.D.4S,
see section 8.5.
Output —— Iout1 —— Assignment8.4.1) —— disabled
PV
SV
TV
QV
Characteristic (8.4.2) —— 4 - 20 unlimited
4 - 20 NE43
Start value —— (8.4.3)
Continued on next page
