Date of issue 11/30/07 805639
HART Loop Converter KFD2-HLC-(Ex)1.D(.**)
Editing device data: HARTcom
22
• Leave empty spaces if necessary.
• Select the position ↵ and then press OK. The character string is saved.
• Or press ESC to exit Custom Tag entry mode without accepting the changes.
8.3 HARTcom
The following illustration shows the HART communication menu. Items from the lowest menu level are
outlined in bold.
HARTcom —— Mode (8.3.1) —— secondary
primary
TimeOut (8.3.2) —— 5 s ...60 s
ShortAddress (8.3.3) —— 0 ... 15
LocateMethod (8.3.3) —— fixed
search
Rebuild (8.3.4) —— On Rebuild
OFF Rebuild
