HART Loop Converter KFD2-HLC-(Ex)1.D(.**)
Editing device data: Parameterization mode
8.1.4 Lowest menu level: select values, enter normal numbers
On the lowest level of the menu, you can either select one of several possible values, or enter a
number for the individual parameters.
Proceed as follows (for floating decimal number, see section 8.1.5):
When entering normal numeric values, please note:
• If you press the S or T keys, the value changes step by step.
• If you hold the S or T keys, the value "rolls" to higher or lower values.
8.1.5 Lowest menu level: enter floating decimal numbers
Enter floating decimal numbers as follows:
• positive numbers with four-digit mantissa, decimal point in or after the mantissa, exponent in three
stages from E-33 and E00 to E33
• negative numbers with minus sign, three-digit mantissa, decimal point in or after the mantissa,
exponent in three stages from E-33 and E00 to E33
Lowest menu level
Parameter
OK →
Current value, flashing
← ESC
S, T: ↓
New value, flashing,
not saved
← ESC
OK ↓
New value, not flashing,
saved
← ESC
