VisuNet FLX System
Product Description
VisuNet FLX pedestal mounted with keyboard/mouse
Figure 3.2 VisuNet FLX mounted into AG-3200-*-Housing on a pedestal PEDESTAL-3200-* with
adapter and optional EXTA4-* keyboard/mouse (ordered separately)
Preferred Configurations:
Note
For a description of the product model nomenclature, see the VisuNet FLX RM, VisuNet FLX
PC or VisuNet FLX DM product datasheets at www.pepperl-fuchs.com. For more mounting
options and information, see the VisuNet Mounting Options datasheet.
Typ e Ty p e C o d e Description
Remote Monitor con-
figuration
RM-320S-NB-22FC-
D-1NKL4A1-NN0
Intel Celeron 3965U
4 GB DDR4, wide temperature grade
64-GB M.2 SATA 3, wide temperature grade
VisuNet RM Shell 6.x (based on Windows®
10 IoT Enterprise LTSC 2021)
PC configuration PC-320S-NB-22FC-
D-1NLP1A1-NN0
Intel Celeron 3965U
8 GB DDR4, wide temperature grade
256-GB M.2 NVMe, wide temperature grade
Windows® 10 IoT Enterprise 2021 x64 LTSC
