VisuNet FLX System
Appendix
Mounting and Installation
No. Type co de Item No. Description
(7) ADAPTER-3200-00-304B-
N0
70129832 0° tilted adapter for pedestal, wall arm,
ceiling mounting for AG-3200-* housing
Surface finish: brushed (Ra <= 0.8 μm)
incl. mounting material to fix adapter to
housing
ADAPTER-3200-00-304A-
N0
70130769 0° tilted adapter for pedestal, wall arm,
ceiling mounting for AG-3200-* housing
Surface finish: brushed (Ra <= 1.6 μm)
incl. mounting material to fix adapter to
housing
(8) ADAPTER-3200-10-304B-
N0
70129831 10° tilted adapter for pedestal mounting
for AG-3200-* housing
Surface finish: brushed (Ra <= 0.8 μm)
incl. mounting material to fix adapter to
housing
ADAPTER-3200-10-304A-
N0
70130768 10° tilted adapter for pedestal mounting
for AG-3200-* housing
Surface finish: brushed (Ra <= 1.6 μm)
incl. mounting material to fix adapter to
housing
(8a) ADAPTER-3200-10-304B-
M12
70144012 10° tilted adapter for pedestal mounting
for AG-3200-* housing
prepared for IDM barcode reader (via
M12 connector)
Surface finish: brushed (Ra <= 0.8 mm)
incl. mounting material to fix adapter to
housing
(9) WALL-BRACKET-3200-
304A-N0
70129835 Adapter for direct wall mounting
compatible with Housing AG-3200-*
(10) PEDESTAL-3200-131-2-
304A-T-N0
70129833 Swivel Pedestal, floor mounting compati-
ble with Housing AG-3200-*
- Height: approx. 131 cm
- Cable glands: 1x M20, 1x M16 (at bot-
tom)
(11) PEDESTAL-3200-131-3-
304A-T-N0
70129834 Swivel pedestal, floor mounting compati-
ble with housing AG-3200-*
- Height: approx. 131 cm
- Cable glands: 1x M20, 2x M16 (at bot-
tom)
- KIT-IDM-Z2-USB-N0 70147948 IDM Z2 USB scanner Kit for VisuNet FLX
3200 System
compatible with mounting adapter
ADAPTER-3200-10-304B-M12
compatible with IDM Z2 USB scanner &
base station
Consists of:
- 1x M12 Panel Feed Through for FLX
mounting adapter (ADAPTER-3200-10-
304B-M12)
- 1x strain relief latch ATEN Lockpro
- 1x cable clamp
