VisuNet FLX System
Product Description
2023-11
15
Interface
Interface type 1 x DisplayPort 1.2 (DP++)
1 x mini DisplayPort 1.2 (DP++ w/ mono locking screw)
1 x Audio Line-out
2 x USB Ex i ports prepared for Pepperl+Fuchs intrinsically safe
keyboard
2 x USB 3.1 Gen1 (5 Gbps) ports
1 x USB 2.0 port
2 x LAN ports (RJ45, 10/100/1000 Mbps)
2 x RS232/422/485 (BIOS configurable) with 5V/12V to power
peripherals (1 x DB9 male + 1 x RJ45)
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (ind. Locations)
EN 61000-6-4:2007+A1:2011
Explosion protection
Directive 2014/34/EU EN IEC 60079-0:2018
EN IEC 60079-7:2015/A1:2018
EN 60079-11:2012
EN 60079-31:2014
RoHS
Directive 2011/65/EU
(RoHS)
EN IEC 63000:2018
Ambient conditions
Operating temperature -20 °C ... 50 °C (-4 ... 122 °F)
Storage temperature -20 °C ... 65 °C (-4 ... 149 °F)
Relative humidity max. relative humidity 93% at 50°C (non-condensing) according
to EN60068-2-78
Climatic conditions Passive cooling, no rotating parts
Altitude Operating altitude max. 2000 m
Shock resistance 18 shocks 15 g, 11 ms all axis, IEC 60068-2-27
Vibration resistance 10 ... 150 Hz, +/- 0.075 mm, 1 g, 10 cycles per axis according to
EN60068-2-6
Mechanical specifications
Degree of protection IP66 / Type 4X
Material Housing: Powder coated, marine-grade aluminium alloy (EN AW-
5754)
Installation System with enclosure
Mass approx. 11.4 kg
aprprox. 13.4 kg with AC Power Supply
with top sunshield: + approx. 1.6 kg
with top and side sunshield: + approx. 3 kg
Dimensions 577 mm x 466 mm x 233 mm
