VisuNet FLX System
Product Description
Directive 2014/34/EU EN IEC 60079-0:2018
EN IEC 60079-7:2015/A1:2018
EN 60079-31:2014
RoHS
Directive 2011/65/EU
(RoHS)
EN IEC 63000:2018
Ambient conditions
Operating temperature -20 °C ... 50 °C (-4 ... 122 °F)
Storage temperature -20 °C ... 65 °C (-4 ... 149 °F)
Relative humidity max. relative humidity 93% at 50°C (non-condensing) according
to EN60068-2-78
Climatic conditions Passive cooling, no rotating parts
Altitude Operating altitude max. 2000 m
Shock resistance 18 shocks 15 g, 11 ms all axis, IEC 60068-2-27
Vibration resistance 10 ... 150 Hz, +/- 0.075 mm, 1 g, 10 cycles per axis according to
EN60068-2-6
Mechanical specifications
Degree of protection IP66 / Type 4X
Material Housing: Aluminium EN AW-5754
Installation System with enclosure
Mass approx. 11.4 kg
aprprox. 13.4 kg with AC Power Supply
with top sunshield: + approx. 1.6 kg
with top and side sunshield: + approx. 3 kg
Dimensions 577 mm x 466 mm x 233 mm
International approvals
UL approval
Approved for UL OrdLoc UL approval E223772
UL61010-1 Ed.3
UL 61010-2-201 Ed2
CAN/CSA C22.2 No 61010-1-12
CAN/CSA C22.2 No 61010-2-201
Approved for UL HazLoc Mounting in
CL I, DIV 2, GP A-D, T4
CL II, DIV 2, GP F, G, T4
CL III
Mounting in
CL I, ZN 2, IIC, T4
CL II, ZN 22, IIIB, T85°C
CL III, ZN 22, IIIA, T85°C
ATEX approval
ATEX certificate UL 22 ATEX 2481X
Directive conformity
