Attaching Housing to Pedestal
1. Carefully turn the housing so that the display is facing up.
1. Using a crane or with the help of another person, place the housing onto the adapter so that the
System Housing bolts align with the adapter slots and the housing rests on the adapter. Tighten
the M5 washers onto the system housing bolts in a criss-cross pattern using a torque of 2.3
Nm.
Figure 4.7 Tighten the four nuts with 2.3 Nm
