Optional: Use the Spare Part Housing Blind Plugs for Strict GMP
Requirement
SPAREPART-AG-320S-BP-P1 (#70136529)
Follow above mentioned steps 1 to 5.
1. Screw the pharma blind plugs with the seal into the housing.
Figure 4.19
2. Tighten them all up with a torque of 2 Nm.
3. Exchange the blind plugs on the right site of the back of the housing with the enclosed pharma
M5 screws. Tighten them up with a torque of 4 Nm.
