User Manual
PEPWAVE AP Series
4.4 AP One Rugged / AP One Rugged M12
AP One Rugged
Front View (AP One Rugged) Rear Panel View (AP One Rugged)
AP One Rugged M12
Front View (AP One Rugged M12) Rear Panel View (AP One Rugged M12)
LED Indicators
Power
On – Power On
OFF – Power Off
Status
RED – Access point initializing
GREEN – Access point ready
Wireless
OFF – 2.4/5GHz Wi-Fi radio off
BLINKING – AP sending/receiving data
GREEN – 2.4/5GHz Wi-Fi radio on
Note that this model can operate in either 2.4GHz or 5GHz mode, depending on Wi-Fi radio
settings.
