Pepwave AP One Series - AP One Flex 300 M Hardware

http://www.pepwave.com 11 Copyright © 5/23/16 Pepwave
User Manual
PEPWAVE AP Series
4.5 AP One Flex 300M
Front View Rear Panel View
Connector Panel (Inside the Lid)
LED Indicators
Status
RED – Access point initializing
GREEN – Access point ready
LAN
OFF – No device connected to Ethernet port
BLINKING – Ethernet port sending/receiving data
ON – Powered-on device connected to Ethernet port
Number of connected clients (1-10, 11-20, 21-30, 31-40)
