http://www.pepwave.com 20 Copyright © 5/23/16 Pepwave
User Manual
PEPWAVE AP Series
AP Name Enter a name to identify your access point. This name can be retrieved via SNMP.
Location Enter a name to identify
via SNMP.
the location of your access point. This name can be retrieved
Admin User This field specifies the administrator username of the web admin. It is set as admin by Name
default.
Admin Password T
public
his field allows you to specify a new administrator password. The default password is
.
Re-enter the admin password.
Check this box to turn on the web administration interface, which allows remote AP
management.
Choose HTTP or HTTPS as the protocol to use when accessing the web admin interface. To
automatically redirect HTTP access to HTTPS, check HTTP to HTTPS Redirection.
Specify the port number on which the web admin interface can be accessed.
Allowed Source IP
Subnets
This field allows you to restrict access to the web admin to only defined IP subnets.
• Any - Allow web admin accesses from anywhere, without IP address restrictions.
• Allow access from the following IP subnets only – Restricts the ability to access web
admin to only defined IP subnets. When this option is chosen, a text input area will
appear:
Enter your allowed IP subnet addresses into this text area. Each IP subnet must be in the form
of w.x.y.z/m. w.x.y.z represents an IP address (e.g., 192.168.0.0), and m represents the subnet
mask in CIDR format, which is between 0 and 32 inclusively. For example: 192.168.0.0/24. To
define multiple subnets, separate each IP subnet, one per line. For example:
192.168.0.0/24
10.8.0.0/16
