38 . DSC 6000 Installation and Hardware Guide
Also included with the DSC 6000 are:
Description Part Number Quantity
Tygon tubing for coolant 02506519 3 m
Teflon tubing for purge gas 02506483 6 m
5/16-in. pipe for Swagelok Cooling Liquid In
and Out connectors
— 2
USB cable — 1
Male RJ45 to DB9 modem cable 09410042 1
Power cable — 1
If you have ordered the CryoFill Liquid Nitrogen Cooling System for your DSC 6000, there will
be additional boxes for the accessories ordered.
Place the analyzer carefully on the prepared bench. Unpack the remaining parts of the
DSC 6000 system and place them nearby. You will need these parts for the installation of the
analyzer.
If you have purchased the CryoFill Liquid Nitrogen Cooling System for your DSC 6000,
remove the parts from their box(es) and place them on a bench nearby.
Unpacking the CryoFill LN2 Dewar
1. With a pocket knife or box cutter, carefully open the top of the dewar box.
2. Remove the packing on the top and the four sides of the dewar.
3. With a pocket knife or box cutter, carefully cut down two adjacent edges of the box
from top to bottom.
4. Roll the dewar out of the box and past the box flap on the floor.
5. Remove the box and all packing to clear the area.
The procedure for unpacking the DSC 6000 is complete.
