Illustration 42 g03393011
Typical example
(9) Diagnostic connector
(10) Electronic Control Module
(11) Atmospheric Pressure Sensor (Barometric Pressure sensor)
(12) Oil pressure sensor
Illustration 43 g03392999
Typical example
(13) Primary Speed/Timing Sensor
48 SEBU8732
Features and Controls
Sensors and Electrical Components
