Soot and NOx Sensors
Illustration 53 g03393956
(10) Soot Sensor (11) NOx Sensors
The location of the soot sensor (10) and NOx sensor
(11) will depend on the application.
SEBU8732
55
Features and Controls
Sensors and Electrical Components
