Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 21
400 Series
Tightening sequence 404C-22 and 404C-22T Operation 3-9
Notes:
l All torques should be checked again after tightening.
l On assembly lubricate cylinder head setscrews with clean oil.
Engine Torque Nm (lbf ft) kgf m
404C-22
404C-22T
Cylinder head setscrews 101 (74.5) 10,3
H1042
12 4
513
16
8
1
9
17
15
7
2
10
18
11
3
6
14
