6
Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 53
400 Series
Angleich
To remove and to fit Operation 6-3
Notes:
l The internal setting for the Angleich must not be altered.
l Apply a little Loctite 275 to threads (2) before assembly.
l The Angleich is not fitted to the 403C-11 engine.
Engine Torque Nm (lbf ft) kgf m
403C-15,
404C-22
404C-22T
Angleich (1) 5 (3.6) 0,5
H1070
1
2
