Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 83
400 Series
Oil pressure switch
To remove and to fit Operation 10-7
The lubricating oil pressure switch can be found in two positions.
1 If fitted on the top cover, the switch (1) is brown in colour and rated to 0,3 kgf/cm² (4.27 lbf/in²).
2 If fitted on the cylinder block, the switch (2) is blue in colour and rated to 1,0 kgf/cm² (14.22 lbf/in²).
Engine Torque Nm (lbf ft) kgf m
All models Oil pressure switch 10 (7.3) 1,0
1
2
H1096
