Back Bar Service Manual
Return to Table of Contents Service Instructions - Door, Drawers, and Shelving Page 8-4
STEP 11.
Place lower V-block into lower cabinet hinge with
notch parallel to cabinet. See Figure 8-8.
Figure 8-8. Installing V-Block
STEP 12.
Lift door assembly and insert top pin into
bearing. Move door toward cabinet and align V-
blocks. See Figure 8-8 and Figure 8-9.
Figure 8-9. Installing Door
STEP 13.
Insert and tighten lower hinge pin to complete
assembly.
Replace Door Hinge
See Section 8.2 for hinge replacement
instructions.
Sliding Door Models
8.4.1 Removing/Installing Sliding Doors
STEP 1.
To remove sliding door, simply grasp door on
each side and lift up off bottom track, then tilt
outwards and pull down to remove from upper
track.
STEP 2.
To reinstall sliding door, place door in upper
track. Be sure to engage bracket. See Figure
8-10.
Lift door up into track and place into bottom
track.
Figure 8-10. Removing/Installing Sliding Door
Bracket
