Back Bar Service Manual
Return to Table of Contents Service Instructions - Door, Drawers, and Shelving Page 8-5
8.4.2 Adjusting Door Spring Tension
Tools required
Tension spring is in upper track of each door.
Figure 8-11. Door Track
To increase or decrease spring tension:
• Remove Phillips screw
• Position bracket in one of three detents
• Reinstall screw
Detent farthest from left provides the least
amount of tension.
Units are shipped from factory with springs set at
the weakest setting.
8.4.3 Torpedo Spring Adjustment
Tools required
STEP 1.
Remove doors.
STEP 2.
Remove screw.
STEP 3.
Pull up spring and attached black tab.
STEP 4.
Feed into next notch to tighten/loosen.
STEP 5.
Tighten screw.
Drawer & Shelf Slides
8.5.1 Shelving Adjustment
Completely empty shelf or drawer before
removing.
STEP 1.
Open door and slide shelf out.
STEP 2.
Press locking mechanism. Tilt shelf and remove
from unit
Figure 8-12. Shelf Locking Mechanism
STEP 3.
Reposition each bracket separately. Grasp middle
of bracket, pull front end up and out, then
forward to remove.
STEP 4.
Place brackets at desired location and reinstall
shelf(s).
Tab
Screw
Spring
Detent
