Perlick BBS60 - Page 65

Back Bar Service Manual
Return to Table of Contents Replacement Parts Page 9-5
BBSLP MODELS
ITEM
NUMBER
DESCRIPTION
1-DOOR
QTY.
2-DOOR
QTY.
3&4-
DOOR
QTY.
01
Condensing Unit, 1/3 HP, 115V
-
-
1
01
Condensing Unit, 1/4 HP 115V
-
1
-
01
Condensing Unit, 1/5 HP, 115V
1
-
-
02
Base, High Side
1
1
1
03
Bracket, Hold Down, Compressor
1
1
1
04
Panel, Baffle, Compressor
1
1
1
05
Rail, Condensate Pan
2
2
2
06
Panel, Outer Side, High Side
1
1
1
07
Panel, Inner Side, High Side
1
1
1
08
Screw, Thread Cutter, 1/4-20 X 5/8
4
4
4
09
Pan, Condensate
1
1
1
10
Gasket
2
2
2
11
Foam Block, Divider Baffle
1
1
1
12
Low Side Shell Assembly
1
1
1
13
Pan, Evaporator, Assembly
1
1
1
14
Coil, Evaporator, 5 X 14 X 1.9
1
1
1
15
Tube, Drain, To Evaporator Pan
1
1
1
16
Tube, Outlet, Evaporator
2
2
2
17
Power Cord with Molded
1
1
1
18
Screw, Sheet Metal, #10 X 1 1/4 Phillips
1
1
1
19
Driver, 12 VDC, 60 Watt, Meanwell Lpv-60-12
1
1
1
20
Bracket, Temp Sensor
1
1
1
21
Sleeve, Sensor Insulating
1
1
1
22
Probe, Temperature, NTC, 10k
1
1
1
23
Screw, Sheet Metal, #10 X 1", Phillips
1
1
1
24
Cover, Back, High Side
1
1
1
25
Standoff, Grille
1
1
1
26
Screw, Machine, #8-32, 2-1/2" Black Zinc Plated
1
26
Screw, Machine, #8-32, 2-1/2" Zinc Plated
Customer Option
27
Screw, #10 X 1/2" Phillips Truss Head SMS, #410
4
4
4
28
Controller Mounting Bracket
1
1
1
29
Control
1
1
1
30
Screw, Sheet Metal, #10-16 X 1/2"
5
5
5
31
Top Pull Down Bracket
2
2
2
32
Screw, Tri-lobe, 1/4-20x 1/2" Phillips Flat Head
2
2
2
33
Wire Harness, Condenser Housing
1
1
1
34
L & S Line, 1 Door, Back Bar
1
-
-
34
L & S Line, 2 Door, Back Bar
-
1
-
