Perlick BBS60 - Page 68

Back Bar Service Manual
Return to Table of Contents Replacement Parts Page 9-8
DZS60 MODELS
ITEM
NUMBER
DESCRIPTION
QTY.
01
Condensing Unit, 1/4 H.P., 115V
1
02
Screw, Machine, #8-32 x 2-1/2" Lg, Phillips Truss Head
1
03
Screw, Thread Cutter, 1/4-20 x 5/8 Hex Washer Head, Type 23, Steel
4
04
Screw, Sheet Metal, #6 x 1/2", Type "A", PH Truss Head - Full Contoured, 18-8
2
05
Screw, Sheet Metal, #10 x 1", PH Pan Head, Type "B", Steel, Hardened
1
06
Screw, #10 X 1/2" PH Truss Head SMS #410 S.S., Type "AB"
9
07
Screw, Sheet Metal, #10-16 x 1/2" Hex Flange Grip-Lite, Type "AB"
20
08
Screw, Thread Forming, 1/4-20 X 1/2"
2
09
Rivet, Pop
20
10
Rivnut, Insert
1
11
Low Side Foamed Assembly
1
12
Gasket, Foam .25"
2
13
Relay, Pump, 120VAC Rating
1
14
Probe, Temperature, NTC, 10K Ohm XW60L, 1.8" Nickel Plated
1
15
Foam, Divider, 12"
1
16
Sleeve, Sensor Insulating
1
17
Tube, Drain, Evaporator Pan to Condenser Pan
1
18
Bracket, Temperature Sensor, Back Bar
1
19
Tube, IO, Evaporator, Back Bar (Crimped for Cap Tube)
1
20
Tube, IO, Evaporator, Back Bar
1
21
Top Pull Down Bracket, Back Bar
2
22
Standoff, Grille, Back Ba
1
23
LED Driver
1
24
Control
1
25
Red Display
1
26
Harness 12 VDC Split Male-Female
1
27
Harness, Line Voltage Split
1
28
Harness Stepper Controller Input
1
29
Standoff
4
30
Panel, Outer Side, High Side
1
31
Panel, Inner Side, High Side, Back Bar
1
32
Base, High Side
1
33
Cover, Back, High Side
1
34
Rail, Condensate Pan, Back Bar
2
35
Pan, Condensate, High Side
1
36
Grille, Front, Back Bar
1
37
Pan, Evaporator, Assembly, Back Bar
1
38
Evaporator Fin Coil
1
