Perlick BBS60 - Page 74

Back Bar Service Manual
Return to Table of Contents Replacement Parts Page 9-14
DDS60-IR, DDS84-IR, DDS108-IR MODELS
ITEM
NUMBER
DESCRIPTION
2-DOOR
QTY.
3&4-
DOOR
QTY.
01
Condensing Unit, 1/3 H.P. 115V
-
1
01
Condensing Unit, 1/4 H.P., 115V
1
-
02
Screw, Machine, 8-32, 2-1/2" Lg Phillip Truss Head, Steel, Black Zinc, Plated
2
2
03
Screw, Thread Cutter, 1/4-20 x 5/8 Hex Washer Head, Type 23, Steel
4
4
04
Screw, Sheet Metal, #10 x 1", PH Pan Head, Type "B", Steel, Hardened
1
1
05
Screw, #10 X 1/2" PH Truss Head SMS #410 S.S., Type "AB"
15
10
06
Screw, Sheet Metal, #10-16 x 1/2" Hex Flange Grip-Lite, Type "AB"
14
20
07
Screw, Thread Forming, 1/4-20 X 1/2"
2
2
08
Rivet, Pop, 1/8" Dome Head, S.S., .063" - .125" Grip Range
26
26
09
Rivnut, Insert, #8-32, Steel, Zinc & Yellow Chromate Plated
1
1
10
Low Side Foamed Assembly
1
1
11
Gasket, Low Perm Polyether Foam .25"
2
2
12
Probe, Temperature, NTC, 10K Ohm XW60L, 1.8" Nickel Plated
1
1
13
Foam, Divider, 12"
1
1
14
Snap Bushing, For 1" Hole, Nylon, Black
1
1
15
Sleeve, Sensor Insulating
1
1
16
Tube, Drain, Evaporator Pan to Condenser Pan
1
1
17
Bracket, Temperature Sensor, Back Bar
1
1
18
Tube, IO, Evaporator, Back Bar (Crimped for Cap Tube)
1
1
19
Tube, IO, Evaporator, Back Bar
1
1
20
Top Pull Down Bracket, Back Bar
2
2
21
Standoff, Grille, Back Bar
1
1
22
Control
1
1
23
Panel, Outer Side, High Side
1
1
24
Panel, Inner Side, High Side, Back Bar
1
1
25
Base, High Side
1
1
26
Rail, Condensate Pan, Back Bar
2
2
27
Pan, Condensate, High Side
1
1
28
Grille, Front, Back Bar
1
1
29
Pan, Evaporator, Assembly, Back Bar
1
1
30
Evaporator Fin Coil
1
1
31
Baffle, Compressor
1
1
32
Bracket, Compressor
1
1
33
L & S Line, 2 Door Back Bar
1
-
33
L & S Line, 3 & 4 Door Back Bar
-
1
34
Power Cord with Molded Receptacle, 14/3, Back Bar
1
1
