5 LiquidWatch Operation
32
CONFIGURATION MENU
BAUD RATE – 9600
LIQUIDWATCH V1.06
PERMAPIPE INC.
CONFIGURATION MENU
7 OF 8 PHONE NUMBER
PH. #: 0-9,D,T or P
9P18479662190
CONFIGURATION MENU
8 OF 8 VERSION
CONFIGURATION MENU
6 OF 8 BAUD RATE
Use the arrow keys to select the correct baud rate (usually 9600). Press “Enter” or “M” to set the rate
and return to the Configuration Menu.
5.7.7 Phone Number
A phone number must be entered if a LiquidWatch system is connected to the PALCOM computer by a
phone modem. The LiquidWatch system will initiate a call to the PALCOM computer if a probe is
activated. If the LiquidWatch system is connected by a short haul modem or a network modem,
the phone number must be erased. To change the phone number, select function 7 from the
Configuration Menu.
The following screen will be displayed. The second line displays the digits entered. The numbers 0 - 9
and letters D (DELAY), T (TONE) and P (PULSE) can be selected by scrolling with the arrow keys.
When the correct digit is displayed, press "ENTER". After all digits are selected, select "T" or "P" to end
the process and clear any following digits. "T" is selected if the phone line has touch-tone service for a
push button phone. "P" is selected if the phone has pulse service for a rotary dial phone. If "T" or "P"
is selected as the first digit, the phone number will be erased. This should be done if the
LiquidWatch system is not connected to a phone modem.
5.7.8 Version
Function 8 displays the version number of the LiquidWatch firmware. Select function 8 to view it. Press
“Enter” or “M” to return to the Configuration Menu.
Press “M” to return to the Main Menu from the Configuration Menu.
