LiquidWatch Installation Manual
3
1 Introduction
1.1 General Description
This LiquidWatch
®
Installation and Operation Manual is intended for use as a general guide for
LiquidWatch Leak Detection Systems. Users (installers) should independently evaluate the suitability of
this information and PermAlert’s products for their application and specific installation. If you received a
PermAlert product that is not described in this manual, contact PermAlert for the appropriate instructions.
1.2 Applications
The LiquidWatch system consists of an electronic microprocessor-based alarm panel that monitors
probes. The probes may be installed in many applications including: secondary contained piping, double
wall tanks, sumps, computer room subfloors, cleanroom subfloors or any area where liquids need to be
detected. There are two LiquidWatch models available:
Model LW64 monitors up to 64 probes in ordinary locations.
Model LW64-IS monitors up to 64 probes in Class I, Division 1, Groups C & D, hazardous
locations.
Each base system will monitor up to 8 probes and has a common alarm output relay. If additional
probes or output relays are required, the following modules are available:
Model RPM-8 is a remote probe module that can monitor up to 8 probes.
Model ORM-4 is an output relay module with 4, 10 A, 250 VAC rated relays.
Model ORP-16 is an output relay panel with 4, 10 A, 250 VAC rated relays, expandable to 16
relays.
1.3 Receiving and Handling Precautions
The following general precautions should be observed:
1. Read this manual carefully before beginning any work. Do not use substitute materials or short
cut recommended procedures. Understanding and following this guide is essential to avoid
installation problems.
2. Collect the needed quantities of all materials well in advance of scheduled work.
3. Check the packing list against received items. Report immediately any shortages or damaged
materials to the delivering carrier.
4. All probes must be tested immediately upon receipt following the probe test procedures contained in
this manual. Report immediately to PermAlert any probes that fail this quality control test.
5. System drawings, provided by the designer, should indicate the extent, general location and
arrangement of leak detection equipment and probes. The contractor (installer) should become
familiar with all details of the installation before proceeding.
6. A qualified electrician should perform electrical work.
1.4 Material and Equipment Normally Supplied by PermAlert
Each system may include the following items as quoted:
1. Leak detection alarm panel
2. Communication cable
3. Lead wire
4. Probe adapter assembly
5. Probes
