5 LiquidWatch Operation
26
MAIN MENU 1 OF 5
SETUP
SETUP MENU SELECT
PROBE # 01 OF 08
SETUP MENU TYPE
HYDROCARBON 1 OF 4
SETUP MENU TYPE
WATER 2 OF 4
LiquidWatch displays “**” in the “seconds” location when the battery needs to be replaced. A
replacement battery, CR2025, is available from PermAlert. If the power is lost when the battery is low or
the jumper is in the “OFF” position, the time and date information will be lost and the clock will be reset to
1/1/2000.
5.1.6 Installation Instructions
Detailed installation instructions are provided in this manual.
**ALL APPLICABLE MANUALS MUST BE REVIEWED AND UNDERSTOOD PRIOR TO
INSTALLATION**
5.2 Operating LiquidWatch
LiquidWatch lists the primary functions in a Main Menu. The LCD displays one menu function at a time.
Read the display carefully. LiquidWatch prompts for the information it needs. Press the “” to
step through the Main Menu and display the next menu function (or “” to display the previous).
Several menu functions have timers that cause LiquidWatch to return to monitoring if no keys are
pressed within a predefined period of time.
This manual uses examples of display messages. “TIME” and “DATE” represent a display of a specific
time or date.
The Main Menu Functions available in LiquidWatch are:
1. SETUP
2. PROBE ON/OFF
3. HISTORY
4. DISPLAY SETUP
5. CONFIGURATION
The normal procedure for setting up a new system is to select function 1 and then answer the questions
displayed on the LCD.
5.3 Setup
LiquidWatch uses the setup function to enter probe data into memory. To select this function press the
“Enter” key when setup is displayed in the Main Menu.
The first message is:
Use the “” and ”” keys to select the correct probe number and then press “Enter”. If the maximum
number of probes installed is shown incorrectly (8 in this case), go to Section 5.7.3 and configure the
system.
Next, select the type of probe installed by scrolling through the list of 4 types. Press “Enter” when the
correct one is displayed. “NC” and “NO” refer to normally closed and normally open, respectively. All
float switches supplied by PermAlert are setup as “NC Contact”.
