View Android™ OS via the Web Management Interface
DEVICE OPERATION: ANDROID™ SCREENSHOT
▶ The Android™ Screenshot page allows users to view and control Android™ on the MPU5 via the
Web Management Interface
Accessing the Android™ Screenshot Page
1
Connect the MPU5 to the
Management Computer
and log into the Web Man-
agement Interface.
2
Click the Node Status tab.
3
Click the Android™
Screenshot button.
2
3
