Persistent Systems Wave Relay MPU5 - Connecting MPU5 to Management Computer

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
49
SOFTWARE SETUP: MANAGEMENT COMPUTER
What Will I Learn?
▶ How to physically connect the MPU5 to the Management Computer
→
Parts List
≈
22-Pin to RJ45 Receptacle
CBL-DATA-2001
Properly Configured Management Computer with Ethernet PortStandard RJ45 Ethernet Cable
Section B: Connecting the MPU5 to the Management Computer
