Persistent Systems Wave Relay MPU5 - Page 129

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
129
DEVICE OPERATION: CONNECTING A PTT DEVICE
1
Connect the cable to the PTT/EUD side
connector on the MPU5.
2
Connect the PTT device to the connector
on the end of the cable.
