TESTING CONNECTIVITY: THROUGHPUT TEST
Position Status: displays GPS status information for the current node. See the Check GPS Status
section for an explanation of these fields.
Clear: clears all data from the table
Note: If Clear is not pressed before beginning a test, the new throughput test data will be append-
ed sequentially to the existing table of data.
Download CSV: downloads all throughput test data in the table as a CSV file
Download KML: downloads all throughput test data in the table as a KML file
Time: date and time for each line of test
data
Interface: interface used to communicate
during the test
SNR (dB): Signal-to-Noise Ratio at which
the destination node is heard
Chain 1/2/3 (dB): Signal-to-Noise Radio for
each chain on the source node
Tx Rate: MIMO or SISO rate used to
communicate between nodes in the format
MIMO|SISO [Rate]:[Number of streams].
Dist (m): distance between nodes, in
meters, if available
Rem Name: Node Name of the destination node
Lcl Name: Node Name of the source node
Rx(%): percentage of the channel used to receive
Tx(%): percentage of the channel used to
transmit
Cs(%): percentage of the channel occupied by
noise
Tl(%): total percentage of channel used
Bw Tx (Mbps): Upload Bandwidth, in Mbps
Bw Rx (Mbps): Download Bandwidth, in Mbps
Interval (s): time interval of the throughput test
for each line of throughput test data
